Uni-Q 2 Way 100mm Square
The KEF Ci100QS - quality that is quite literally out of sight! Purpose-built for flush mounting into walls and ceilings, the Ci100QS delivers KEF's renowned audio quality as unobtrusively as possible. Part of our Soundlight Series of unobtrusive architectural speakers, the Ci100QS is diminutive in size but not in performance!
Ci100QS
The popular Soundlight Series is yet another major innovation form KEF. When installed, Soundlight speakers are so tiny that they blend in with halogen light fixtures yet will amaze you with their astonishing performance, thanks to KEF's patented Uni-Q's exceptionally wide dispersion.
Fast and Easy to Install
KEF's Ci loudspeaker design makes them so quick and easy to install that once the wire is run and the hole is cut in your wall or ceiling you can be listening to music in less than two minutes.
The Details
SPECIFICATIONS
Nominal Impedance
4 Ohms
Sensitivity
88dB (2.83V/ 1m)
Frequency Response
80 - 27kHz (±6dB) 2pi/open-backed
Crossover Frequencies
3kHz
Drive Units
LF: 100mm (4in.)
HF: 19mm (0.75in.)
HF: 19mm (0.75in.)
Recommended Amplifier Power
10 - 50 W
Product External Dimensions
H x W x D : 127 x 127 x 76 mm (5.0 x 5.0 x 2.99 in.)
Cut-out Dimensions
H x W : 112 x 112 mm (4.41 x 4.41 in.)
Mounting Thickness
Ceiling Thickness (Maximum): 24mm (0.95 in.)
Ceiling Thickness (Minimum): 6mm (0.24 in.)
Ceiling Thickness (Minimum): 6mm (0.24 in.)
Optional Rough In Frame
RIF100S
Optional Rear Enclosure
RNC100S
Mounting Depth From Surface
Without back can : 72mm (2.83in.)
Net Weight
0.67kg (1.48lbs.)
Unit Measurement
Piece
Downloads
Remarks
KEF reserves the right, in line with continuing research and development, to amend or change specifications. E&OE.
KEF reserves the right, in line with continuing research and development, to amend or change specifications. E&OE.
Please visit our Ci Software Download page for more details.
